Specification
|
Product Name
|
Marine Gear Box Accessories |
|
Model
|
MRP 1702W-560 |
|
Ratio
|
1/57.57 |
|
Weight
|
1600 kg |
|
Gear oil
|
29 |
Overview
Marine gear box (or Marine gear reducer, ship main power gear transmission device) is the main propulsion transmission device of the ship power system, which has the functions of reversing, clutch, deceleration and bearing propeller thrust. It is widely used in various passenger and cargo ships, engineering ships, fishing boats, offshore and ocean-going ships, yachts, police boats, military ships and so on.
Classify
Marine gear box in various forms, according to the transmission mode and structural form can be divided into the following categories:
• Reduction gear box
• Clutch reduction gear box
• Reverse and clutch reduction gear box
• Multi-speed gearbox
• Multi-branch transmission gear box
• Multiple parallel gearboxes
• Fuel wood combined power transmission gearbox, etc
In addition, according to the use can be divided into ship main propulsion transmission and auxiliary engine transmission, ship operation mechanical transmission; According to the working conditions can be divided into light load high-speed ships and medium and heavy load ships. From the transmission form, there are fixed pitch transmission gearbox and variable pitch transmission gearbox; The structure form has parallel shaft drive, Angle drive, same center, horizontal center, vertical center and so on.
Application
Marine gearboxes are widely used in all types of ships, including but not limited to:
• Large commercial ships, passenger ships and transport ships.
• Warships and cargo ships.
• Work boat, tugboat, fishing boat, ATV, etc.
• Yachts and other small vessels.
Notice
1、Gear cover protection:
gear in operation will produce high-speed rotation of power, easy to cause injury. Therefore, a cover should be installed around the gear to avoid personnel straying into the gear working area.
2、Gear operation procedures:
Operators should master the use of gear procedures and operating skills to avoid accidents caused by wrong operation.
3、Gear maintenance:
Regular maintenance and maintenance of the gear, check the working status of the gear, timely replacement of worn parts, improve the working efficiency and safety of the gear.
4、Gear anti-slip measures:
Take anti-slip measures to ensure the stability and safety of the gear.
